Home | Coating Systems | Traffic Coating Systems | Auto-Gard Systems | Auto-Gard F New
banner image

Auto-Gard F New

Two component, urethane/epoxy hybrid system with coarse flint aggregate for high traction applications

Auto-Gard F is a high solids, low-odor hybrid system ideal for steep ramps and other applications where increased texture is needed to prevent slip/skid of vehicles.

Product Specifications
Application Methods
Product Literature
Technical Documents
FAQs

System Overview

Auto-Gard F is ideal for all traffic service levels, from multifamily housing to hospital and retail garages. An epoxy wear coat provides the durability required for high-traffic areas, and the #3 flint aggregate gives this system our most aggressive non-slip properties.

Epoxy and urethane topcoats are available (consult with Neogard to determine the best option for your project). A variety of colors are available for both topcoats.

Contact Us

Selected Physical Properties

Product Description Test Method Results
70714/70715-09 topcoat Taber Abrasion ASTM D4060 61 mg/1,000 CS-17
FC400/FC600 topcoat Taber Abrasion ASTM D4060 10 mg/1,000 CS-17

Consult Neogard Product Data Sheets and Guide Specifications for a complete list of physical properties.

Use Area:

Vehicular Traffic, Steep Ramps, High Traction

Type:

Urethane/Epoxy

Features:

  • Epoxy wear coat
  • Flint aggregate
  • Proven history

Benefits:

  • Higher durability vs urethane
  • Does not crush and provides heavy texture
  • Documented performance

Ask us about Auto-Gard F

Our Neogard Experts team is glad to tell you how Auto-Gard F is the best coating system to protect your investment.

1-833-443-6735

Contact Us

What is Lorem Ipsum?

Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book.

What is Lorem Ipsum?

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vestibulum ut augue in magna varius bibendum.

What is Lorem Ipsum?

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Aenean sed ex nec mi lacinia fermentum.

What is Lorem Ipsum?

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Cras feugiat libero sit amet dolor tristique, sed porta nunc varius.

Lorem Ipsum

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Proin sed dolor vitae mi lacinia ultrices.

Lorem Ipsum

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nunc accumsan sapien nec arcu tincidunt luctus.

Lorem Ipsum

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Curabitur non libero ut diam suscipit malesuada.

What is Lorem Ipsum?

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Sed tempor lorem ut tincidunt tincidunt.

Plant Image

Auto-Gard F System Build

Before application, always check Neogard Product Data Sheets and Guide Specifications for mixing instructions and other important information.

Auto-Gard F

Auto-Gard F

Coat Product Coverage Rate Mils WFT/DFT
4 - Topcoat 70714/70715-09
FC400/FC600 topcoat
66 sf/gal
61 sf/gal
24/24
26/24
3 - Wear 70714/70715-09 +
#3 flint aggregate
133 sf/gal
30 lb/100 sf
12/12
2 - Base FC7500/FC7960 80 sf/gal 20/20
1 - Primer 7760/7761
7780/7781
7797/7798
300 sf/gal
300 sf/gal
300–500 sf/gal
NA

Product Literature

Files may be downloaded individually or in a submittal package. Choose a language to select a file. Select one file and click the download button to the right, or select multiple files and click the “Download Selected” button below.

Technical Documents

Files may be downloaded individually or in a submittal package. Choose a language to select a file. Select one file and click the download button to the right, or select multiple files and click the “Download Selected” button below.

Safety Data Sheets (SDS)

FAQs

How long does Auto-Gard F need to cure before opening to vehicular traffic?

Typically the coating needs to cure 24 hours before opening to vehicular traffic. In cooler temperatures this time may as may be 24-36 hours.

What type concrete curing compounds can be used with Auto-Gard F?

It is best to water cure concrete or use a sodium silicate curing compound. The use of acrylic or other “film forming” compounds will create bond issues and must be removed.

What is the minimum temperature at which Auto-Gard F can be applied?

The coating should be applied at temperatures that are 40°F/4°C and rising during application.

What is the maximum concrete temperature that Auto-Gard F can be applied?

The coating should not be applied to deck surfaces that are =/> 100°F/38°C.

You can trust Auto-Gard F in your next project

High-performance protection tested under the harshest environments. Auto-Gard F was developed to endure intense vehicular traffic while providing a seamless, durable, skid-resistance membrane to prevent the ingress of moisture and chloride intrusion.
