RTS Water Feature System

Urethane waterproofing system for use in fountains and reflecting pools

The RTS Water Feature System is a PUMA/MMA system for water features offering multiple color options. For exterior applications or those where color is desired, the Acrylithane topcoat can be tinted to match any color.

Product Specifications
Application Methods
Product Literature
Technical Documents
FAQs

System Overview

Neogard RTS Water Feature System is specially designed for use in decorative water features like fountains and reflecting pools. The system offers outstanding water containment and fast return to service. Our 7825/7821 two-component urethane provides outstanding water containment, and the optional Acrylithane HS2 or HS4 topcoat can be tinted to match any color scheme.

Please note: This system is not for use in swimming pools, cooling towers, or potable water tanks.

Selected Physical Properties

Product	Description	Test Method	Results
7825/7821 urethane	MVT	ASTM E96	0.5 English Perms at 20 mils
7825/7821 urethane	Elongation	ASTM D412	200%
7825/7821 urethane	Tensile Strength	ASTM D412	1,500 psi

Consult Neogard Product Data Sheets and Guide Specifications for a complete list of physical properties.

Use Area:

Fountains, Reflecting Pools

Type:

PUMA/MMA

Features:

Excellent elongation
Top coat color options

Benefits:

Provides crack bridging/waterproofing
Adds beauty to water feature

Ask us about Pool-Gard C

Our Neogard Experts team is glad to tell you how Pool-Gard C is the best coating system to protect your investment.

1-833-443-6735

RTS Water Feature System Build

Before application, always check Neogard Product Data Sheets and Guide Specifications for mixing instructions and other important information.

RTS Water Feature System

Pool-Gard C

Coat	Product	Coverage Rate	Mils WFT/DFT
6 - 2nd Exterior Finish	Acrylithane HS2 Acrylithane HS4	200 sf/gal	8/5 8/4
5 - 1st Exterior Finish	Acrylithane HS2 Acrylithane HS4	200 sf/gal	8/5 8/4
4 - Exterior Primer	Ureprime HS4	300 sf/gal	NA
3 - Topcoat	7825/7821	66 sf/gal	24/24
2 - Base	7825/7821	66 sf/gal	24/24
1 - Primer	7740/7741	200 sf/gal	NA

Product Literature

Files may be downloaded individually or in a submittal package. Choose a language to select a file. Select one file and click the download button to the right, or select multiple files and click the “Download Selected” button below.

Technical Documents

selected

Safety Data Sheets (SDS)

FAQs

How long does the RTS Water Feature System need to cure before opening to pedestrian traffic?

Typically the coating needs to cure 48 hours before opening to pedestrian traffic. In cooler temperatures this time may be 72 hours.

What type of concrete curing compounds can be used with the RTS Water Feature System?

It is best to water cure concrete or use a sodium silicate curing compound. The use of acrylic or other “film forming” compounds will create bond issues and must be removed.

What is the minimum temperature at which the RTS Water Feature System can be applied?

The coating should be applied at temperatures that are 40°F/4°C and rising during application.

How soon after application can water feature be filled with water?

System must be cured for a minimum 10 days prior to being filled with water.

You can trust Pool-Gard C in your next project

High-performance protection tested under the harshest environments. Pool-Gard C can make your fountain or reflective pool great looks and reliable protection.
